C-flex 500750 couplings
C-Flex couplings are designed to connect two rotating shafts, accommodating large misalignments while transmitting high torque loads with zero backlash. Their construction ensures a low moment of inertia and minimal impact on system dynamics. A large through hole allows for smaller couplings to fit larger shafts, and the ability to disassemble before installation makes them ideal for retrofit applications. These features make C-Flex couplings an efficient and versatile solution for various mechanical systems.
| P/N | OD | L | Min Bore A/B | Max Bore A/B | H | Set Screw Size | Max Torque (Lb*In) | Max RPM | Max Angular Offset (Deg.) | Max Parallel Offset | Max Axial Offset | Weight (oz.) | Static Torsional Stiffness (Lb*In/Deg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 500750 | 0.75 | 1.375 | 0.125 | 0.375 | 0.475 | M4 X 0.7 | 12 | 10,000 | 7 | 0.01 | 0.02 | 0.74 | 11 |
| 50100 | 1 | 1.5 | 0.25 | 0.5 | 0.474 | M4 X 0.7 | 24 | 7,500 | 7 | 0.015 | 0.025 | 1.41 | 27 |
| 501250 | 1.25 | 1.65 | 0.375 | 0.625 | 0.46 | M5 X 0.8 | 48 | 7,500 | 7 | 0.015 | 0.03 | 2.16 | 51 |
| 501500 | 1.5 | 2.25 | 0.5 | 0.75 | 0.704 | M6 X 1.0 | 75 | 5,000 | 7 | 0.02 | 0.03 | 4.35 | 89 |
| 501750 | 1.75 | 2.6 | 0.625 | 0.875 | 0.755 | M6 X 1.0 | 135 | 5,000 | 7 | 0.02 | 0.04 | 6.69 | 135 |
| 502000 | 2 | 2.85 | 0.75 | 1 | 0.816 | M8 X 1.25 | 180 | 3,750 | 7 | 0.025 | 0.05 | 9.92 | 205 |
| 502500 | 2.5 | 3.1 | 0.875 | 1.25 | 0.793 | M8 X 1.25 | 300 | 3,750 | 7 | 0.025 | 0.05 | 16.45 |
