Electrical Specifications
Parameters and Specifications
Continuous Rated Current: 30A @ 600V AC / 250V DC
Rated Insulation Voltage (Ui): 600V (UL/IEC)
Horsepower Ratings (HP): 230V: 7.5 HP
460V: 15 HP
575V: 20 HP
250V DC: 5 HP
Maximum Power for IEC Applications (kW): 220V: 5.5 kW
440V: 11 kW
550V: 15 kW
Auxiliary Contact Configuration: 2 Normally Open (NO) Contacts
Rating: 10A @ 600V AC (NEMA A600)
Short-Circuit Withstand Capacity: Without fuses or with Class H fuses: 10,000 A
With Class J/R fuses: 200,000 A
