Product Overview
The Siemens 3RT6028-1AN20 contactor is a high-performance industrial-grade electrical component, designed for high-load applications and widely used in various electrical control systems.
Product Features
This contactor has a rated current AC-3 of 38A, a coil voltage of 220V AC 50/60Hz, equipped with one normally open and one normally closed auxiliary contact. With a 3-pole design, specification S0, and screw terminals, it ensures stable and convenient installation. Its mechanical life reaches 10 million operations, showing high reliability. In terms of electrical performance, the insulation voltage measurement is 690V, and the impulse withstand voltage capability measurement is 6kV, enabling it to effectively cope with complex electrical environments. It also features low power consumption, with a power of only 3.8W per electrode during hot-state current measurement and a typical no-load current share of 2.62W, achieving significant energy-saving effects. Additionally, it complies with the RoHS directive.
