Lenze ERBM200R100W Brake Resistor
1. Product Overview
Model: ERBM200R100W
Type: Brake Resistor, used to consume the regenerative energy of the inverter/servo system
Main Application:
Prevent DC bus overvoltage
Quickly brake the motor (such as cranes, elevators, conveyor belts, etc.)
2. Key Parameters
Parameter Specifications
Rated Power: 100 W (continuous operation)
Peak Power: 200 W (short-term overload)
Resistance (Ω): 200 Ω (specific information is subject to the label)
Voltage Level: Adapt to DC bus voltage (usually 400V DC)
Protection Level: IP20 (need to be installed in the electric cabinet)
Cooling Method: Natural air cooling (no fan)
Working Temperature: -25°C ~ +400°C (surface temperature)
Terminals: Screw terminals (usually 2-wire)
3. Features
Energy-efficient design:
High-temperature resistant metal alloy resistance wire, excellent heat dissipation performance.
Strong short-term overload capacity, suitable for frequent start-stop scenarios.
Safety protection:
Built-in temperature fuse (optional), automatically disconnected when overheated.
Insulating ceramic/mica substrate, short-circuit proof design.
Compatibility:
Optimized for Lenze inverters (such as 9300, i500/i700 series).
Also compatible with other brands of drives (matching resistance and power required)
