The EPC1200 is the newest innovative concept of thermal panel-mount printer. Its ultra small design and easy design-in requirements, make it as a perfect solution for most of aplications where a low-cost and high-performance printer unit is essential, combining both panel-mount with system-integration structures.

Its high speed printing of 90mm/s and its reduced dimensions (108 x 88 x 67mm) put Fenix Imvico EPC1200 in the first rank of panel printers in the market.

• Easy paper replacement

• Ultra compact and lightweight design

• Easy design-in requirements

• Low-cost printer

• 58mm paper width

• High speed printing, up to 90mm/s

• Resolution: 8 dot/mm (203 dpi)

• Serial RS232C & parallel IEEE1284, or USB ports on-board

• High quality printing through automatic regulation of printing energy

• 12 to 24Vdc or 5Vdc single power drive

• Maximum power current consumption programmable

• Graphic bitmap printing capability, reverse and bold text

• Scalable fonts up to 64 times (in X/Y axis)

• Command list compatible to Epson ESC/POS protocol

• Character and line spacing programmable

• Upload of logos and font tables, and firmware upgrades via PC

• Hexadecimal mode for easy software debugging

• 7Kbyte input data buffer

• Barcodes printing capability (EAN13, Code 39, Code 128 and ITF)

• 3 maintenance counters (ON/OFF times, operation time and meters of paper printed)

• Windows and Linux drivers available

Applications

Panel-mount printers for industrial machinery Fenix Imvico

Panel-mount printers for electro-medical equipment Fenix Imvico
