EGS21 VM-24-B Specifications
Electrical Specifications
Power Input: 24V DC system (with built-in step-down resistor in the instrument)
Measurement Range: 16 – 36V (suitable for 24V systems)
Output Type: Hall effect switch, outputting a grounded signal (sinking output)
Triggering Method: Incremental triggering (suitable for voltmeters)
Saturated Output Voltage: 1.3–2.3V at 25℃
Output Rated Current: 300mA constant current (for EGS21 model)
Overvoltage Protection: Can withstand up to 200% of nominal voltage for 5 minutes
Reverse Polarity Protection: Can withstand indefinitely within the operating temperature range
Mechanical & Environmental Specifications
Enclosure: Polyester (PBT), impact-resistant and waterproof
Bezel: SAE type, low-handled stainless steel (Option B)
Mirror: UV-resistant, transparent glass inset
Dial:
Black background with white markings
Red markings when backlight is activated
Mirror band design to eliminate visual errors
Operating Temperature: -40℃ to +85℃ (-40℉ to +185℉)
Storage Temperature: -60℃ to +85℃ (-77℉ to +185℉)
Wiring: Plug and lead wires, 18AWG (1.0mm²), wire length 8 inches (203mm)
