Measurements:
Pressure: PSI and bar (Pressure Transducer)
Temperature: Fahrenheit and Celsius
Volume Flow: US GPM and LPM (Flow Turbine)
Rotational Speed: RPM
Technical Data:
Connections: 2 x M12 5-pin female
Designation: CAN1xx, CAN2xx, each galvanically isolated
Channels CAN1xx: 24
Channels CAN2xx: 24
Standards: CAN 2.0 A, CAN 2.0 B
Protocol Support: CANopen, SAEJ1939, and CAN generic, mixed operation of several CAN protocols possible
Terminating resistor: Can be switched on/off
Signal Connection Supply: Passive, no external supply
Operating Temperature Range: 14 to 122 °F (-10 to 50 °C)
Weight: 0.3 lbs (127 g)
Dimensions：11 × 9 × 4 in
Description：CAN Input Module
Inputs：2 CAN bus networks, 24 CAN bus channels each for connection with CAN (CAN 2.0 A, CAN 2.0 B) systems like CANopen, CAN generic, and SAE-J1939.
