Germany ASM WS1205351750 is an analog angle sensor, which can also be used as a displacement sensor.
It has a wide measurement range and can perform continuous rotation measurement within 345°, 180°, or 90°. This sensor is of potentiometer type, with a rated voltage of 10V and an operating current range of 4 - 20mA.
Its protection grade is as high as IP67, enabling it to adapt to harsh environments. The sensing device adopts a precision potentiometer, featuring both voltage and current output, and the resolution is basically unlimited. Made of aluminum and stainless steel, it is sturdy and durable. It can rotate clockwise to increase the output signal, with a maximum speed of 10,000 revolutions per minute and a torque of 1NCM.
It weighs about 450 grams and is widely applied in industrial fields requiring precise angle or displacement measurement.
