ASCO E290B053 Angle seat valve
It is a high-performance pneumatic angle seat valve designed for industrial fluid control and suitable for efficient on-off control of liquids, gases and steam. The valve adopts a 45° angle seat structure and has the characteristics of large flow, low flow resistance and fast response. It is widely used in food and beverage, pharmaceutical, chemical and HVAC industries.
Core features
Valve body and materials
Valve body material: stainless steel (CF8M, corrosion-resistant)
Seal material: PTFE (standard, high temperature and chemical corrosion resistant)
Interface size: DN50 (2")
Pressure range: 0~16 bar
Temperature range: -10°C ~ +180°C (standard PTFE seal)
Pneumatic actuator
Drive mode: single-acting (spring return) or double-acting (optional)
Working air pressure: 4~8 bar
Response time: ≤1 second (fully open/fully closed)
Fluid performance
Flow coefficient (Cv): 65 (large flow design)
Applicable media:
Liquids (water, oil, chemical liquids)
Gases (compressed air, steam, inert gases)
Corrosive media (optional EPDM or FKM seals)
Structural features
45° angle seat design: reduces flow resistance and pressure loss
Self-cleaning valve seat: reduces impurity accumulation and prolongs service life
Visual position indicator: intuitively displays the valve switch status
Manual operating device (optional): supports manual switching
