axxair samx-25 Microfit welding heads
Diameter ø0.236 - ø1
Microfit closed head with cassette for orbital TIG welding, powered by SAXX power source
High level of performance with a high duty cycle
Grease-free operation: compatible with clean room standards
Optimal positioning of tubes and fittings in the cassette with an optimized clamping system, without risk of deforming the part to be welded
Optimized inert gas diffusion: welds with very limited coloration
Easy maintenance and cleaning : thanks to a tool integrated in the machine body
Air or water cooled
Technical characteristics
- 0,236’’ to 1’’, ø 6 – ø25,4 mm
-The SAMX-25 is a cassette type orbital welding head. It is controlled by AXXAIR’s power sources.
- The SAMX-25 machine can weld different tube configurations
- Single integrated tool for disassembling the machine, adjust/change the electrode and position the jaws
- Constant effort cassette locking lever: Stable holding of the cassette, without the risk of over tightening
- Integrated remote control (start/stop, gas and electrode rotation)
- Illuminated logo while welding
- Belt hook
- Weight : 6.5 kg (13 lbs) with 8 meters (26ft) cable
- Delivered in a shockproof case
