I. Basic Electrical Characteristics
• Rated Insulation Voltage (Ui): 690V AC
• Rated Operational Voltage (Ue):
◦ IEC Standard: 690V AC
◦ UL Standard: 600V AC
• Rated Impulse Withstand Voltage (Uimp): 6kV
• Rated Frequency: 45...65 Hz
• Number of Poles: 3 Pole
• Application: Supports Single-phase or Three-phase Operation
II. Power Supply Specifications
• Operational Voltage Range:
◦ 85...132V AC
◦ 159...265V AC
• Maximum Inrush Current: 6A
• Maximum Power Consumption:
◦ CEP9 Main Unit Only: 6W
◦ CEP9 with Expansion Module: 8W
• Maximum Power Supply Interruption Time: 10ms (under Vmin and Vmax conditions)
