SMC VT307-5GS-01-F Solenoid Valve-valve-Effsen Automation

SMC VT307-5GS-01-F Solenoid Valve

Date: 2025-05-13

Brand: SMC

Models: VT307-5GS-01-F

Price: Phone or Email Inquiry

Do you have any questions about this product? Please contact our customer service by phone number +852 30623028 Or Quick Inquiry Form.

Product Overview

SMC VT307-5GS-01-F Solenoid Valve

3-Port Solenoid Valve, Direct Operated, Poppet Type, Rubber Seal, VT307 Series

Standard specification table

Switching method: Direct-acting 2-position single solenoid valve

Applicable fluid: Air

Working pressure range: 0 to 1 MPa (high pressure type), 0 to 0.7 MPa (standard type)

Ambient temperature and working fluid temperature: -10 to +50°C (no freezing)

Response time*1: 20 ms or less (at 0.5 MPa)

Maximum operating frequency: 10 Hz

Lubrication: Not required (If lubricated, use grade 1 turbine oil ISOVG32)

Manual operation: Non-locking, push-type

Installation direction: Any

Shock resistance/vibration resistance*2: 150/50 m/s²

Protection level: Dustproof

Electrical interface: Sheath, DIN terminal
