NIVELCO WGS-214-8 Conductive Level Electrode
Brand: NIVELCO
Model: WGS-214-8
Model Number Breakdown
WGS: Conductive level electrode series, used with NIVOCONT series conductive level controllers
214: Electrode structure specification, multi-electrode rod assembly
8: Effective electrode detection length 800mm
Specifications
| Item | Specification |
|---|---|
| Measuring Principle | Conductive, forms a circuit by conducting liquid through electrode rods to identify high/low levels. Only for conductive liquids, media conductivity ≥10μS/cm |
| Wetted Material | Electrode rod 316L stainless steel, insulation sleeve PP polypropylene |
| Media Temperature | 0 to 80°C |
| Operating Pressure | Atmospheric pressure, max. 6 bar |
| Mounting Thread | G1½ male thread, top mounting |
| Number of Electrodes | Multi-electrode combination, enables simultaneous high and low level multi-point detection |
| Protection Rating | IP65 |
| Compatible Controller | NIVELCO NIVOCONT KKH series conductive level controller |
Features
Multi-point integrated conductive electrode; one probe can achieve multiple level control points for automatic water tank high/low level filling, overflow protection, and low level alarm. PP insulation parts resist general weak acids and bases; 316L electrodes resist water, wastewater, and diluted chemical media. Top threaded mounting, vertically inserted into the tank, simple installation, no moving parts, no jamming risk, less prone to blockage by suspended solids compared to float switches. AC low-voltage detection signal reduces electrode polarization and scaling, extending service life. Modular electrode rods can be cut to length or individually replaced as needed.
