CARLO GAVAZZI DPB01CM48 relay
Selected parameters OUTPUT SIGNAL 1 relay SETPOINTS 2, adjustable MONITORED VARIABLE 3-phase AC voltage monitoring Others SIZE 22,5 mm POWER SUPPLY RANGE 380÷480 VAC MONITORING FUNCTION Under and over voltage, phase sequence, phase loss MOUTING DIN-rail INPUT RANGE 380÷480 VAC DELAY 1, adjustable
Three-phase multifunction control relay, three-phase with neutral, TRMS, With phase sequence detection
3-phase monitoring relay for phase loss, sequence, over or undervoltage, nominal range 380-480 V AC, delay on alarm 0.1-30 s, SPDT relay output, regenerated voltage detection, 22.5 mm DIN-rail housing
Mounting
Industrial DIN-rail
Function
Phase sequence; Phase loss; Overvoltage; Undervoltage
3-phase voltage range
380-480 Vac; 440-480 Vac
Frequency range
50-60 Hz
Output
1 relay
Time delay
Delay on alarm
Approvals, marks, declaration
for Europe; for North America; for China; for Australia
Setting method through NFC
No
