Barksdale 9048-3 Sealed Piston Pressure Switch
Brand: Barksdale
Series: 9048 Sealed Piston Series
Specifications
| Item | Specification |
|---|---|
| Model | 9048-3 |
| Adjustable Range | 100-1425 psi (6.8-96.9 bar) |
| Approx. Deadband | 10-170 psi (0.68-11.7 bar) |
| Proof Pressure | 7500 psi (517 bar) |
| Switch Type | Single pole double throw (SPDT) snap action |
| Switch Rating | 10A @ 125, 250, or 480 VAC; 0.03A @ 250 VDC |
| Accuracy | ±2% of adjustable range |
| Wetted Parts | 416 stainless steel fitting, Buna-N O-ring, 440 stainless steel piston |
| Enclosure | Anodized aluminum, NEMA 13 |
| Pressure Connection | 1/4"-18 NPT Female |
| Electrical Connection | 1/2" NPS conduit connection to screw terminals |
| Operating Temperature | -40°F to +165°F (-40°C to +74°C) |
| Storage Temperature | -40°F to +200°F (-40°C to +93°C) |
| Approvals | UL/CSA |
| Shipping Weight | 2.5 lbs approx. |
Product Features
High reliability, extremely long life, oil and dust tight, easy setpoint adjustment, high proof pressure, rugged design.
Applications
Machine tools, hydraulic presses, compactors, hydraulic power units, compressors.
