Approximate Dimensions (inches) Height x Width x Depth: 2.44 x 0.81 (hexagonal)
Pilot Pressure Range (psi): 40-65 for Optimal Lifespan
Operator Function: The operator resets within ~0.5 seconds, regardless of the existing pilot pressure.
TAC Operator Type: Air Pilot Operator with Reset Function
Air Operators for 2-way or 3-way TAC Valve Models - Sold Separately: 31P
Air Operators for 4-way TAC Valve Models - Sold Separately: 41P, 41PP, 42P, 42PP, 42PA
Installation Method for Button Valve: Connect to the valve collar using a 15/32-32 thread.
Material: Brass, Nitrile Butadiene Rubber (NBR)
