Flow: 1 – 15 GPM (4 – 55 Lpm).
Pressure: 3500 PSI (240 bar).
Ports: #10 SAE
Rugged and Reliable – These meters are constructed with all metal pressure vessels that allow safe & permanent installation.
Bi-Directional – Measures bi-directional flow measurement for liquids.
Use these flow meters to set up, adjust, and test hydraulic pumps, motors, cylinders, and more!
The only way to test a pump and motors safely and effectively is to use a flow meter.
Specifications:
Materials: Anodized aluminum casing and end ports with stainless steel internals.
Pressure Seals: Buna-N®
Threads: SAE J1926/1
Temperature Range: -20 to +240 °F (-29 to +116 °C)
Pressure Rating: Aluminum Operating: 3,500 psi/241 bar max.
Accuracy: ±4% of full scale.
Repeatability: ±1%
Calibration: 0.873 Specific Gravity – For use with hydraulic oil.
Viscosity: Up to 110 cSt.
Weight 1.2875 lbs
Dimensions 8.75 × 4.5 × 4.5 in
Pressure
3500 PSI (240 Bar)
Flow
1 to 15 GPM (4 to 55 LPM)
Length
6.6 inches (168 mm)
Port Thread
#10 ORB (SAE)
