The Bimba FSM-0930-MT is a square metric Flat-1® ultra-thin series double-acting cylinder from the United States. With a square body measuring just 9 mm in thickness, a bore diameter of 30 mm, and a stroke length of 3 mm, it is specifically engineered for applications with extremely narrow spaces. The entire cylinder features an anodized aluminum body paired with a stainless steel piston rod, along with low-friction composite seals. It offers a maintenance-free lifespan of ≥5,000 km within a pressure range of 0–0.7 MPa and a temperature range of -20–80 ℃. The M5 magnetic reed switch slots on both sides support contactless detection. The front end provides a combination of three-sided through-holes and threaded mounting options, delivering fast response and high rigidity. This cylinder is well-suited for micro-stroke clamping, positioning, and lifting in high-density fixtures within the electronics, medical, packaging, and other industries.
