The ASM posiwire® WS10SG is a rugged, high-precision draw-wire displacement sensor with a 10,000 mm measurement range, IP67 protection, and magnetic linear encoder technology, designed for reliable performance in demanding industrial environments.
Optional magnetic absolute encoder
Specifications:
Output - Potentiometer 1 kΩ
Voltage 0... 10 V, 0.5 … 10 V
Current 4 ... 20 mA, 2 or 3 wire
Voltage or current output, programmable (PMUV/PMUI)
SSI
CANopen
SAE J1939
Incremental encoder
Resolution - Analog: <0.002 % f.s.
Incremental 10 pulses/mm, 25 pulses/mm
SSI/CAN-Bus: up to 10 µm
Sensing device - Precision potentiometer
Optical encoder
Magnetic absolute encoder
Housing material - POM and aluminum
Cable: stainless steel
Connection - Connector M12
Weight - Approx. 400 g
