SICK WS/WE24-2B230 Photoelectric sensors
Power consumption transmitter: 50 mA 3)
Power consumption receiver: 40 mA 3)
Switching output: NPN, PNP
Switching mode: Light/dark
Switching mode selection: Selectable via PNP/NPN selector, selectable via light/dark selector
Output current Imax. ≤ 100 mA
Response time ≤ 500 µs 4)
Switching frequency: 1,000 Hz 5)
Acceptance angle: Approx. 2.5°
Connection type: Terminal connection with M16 gland
Protection class: II 9)
Weight: 660 g
Housing material: Metal, zinc die-cast
Optics material: Plastic, PMMA
Functional principle: Through-beam photoelectric sensor
Dimensions (W x H x D): 27 mm x 87.5 mm x 65 mm
Housing design (light emission): rectangular
Maximum sensing distance: 0 m ... 60 m
Sensing distance: 0 m ... 50 m
Focal length: approx. 1°
Light source type: Visible red light
Light source: LED 1)
Light spot size (distance): Ø 700 mm (50 m)
Scattering angle: approx. 1°
Adjustment: potentiometer
