Baumer IFRM 05P15A1/S35L Inductive proximity switch
General data
Mounting type:Flush
Nominal sensing distance Sn:1 mm
Hysteresis:2 … 20 % of Sr
Output indicator:3 port LED red
Electrical data
Switching frequency:5 kHz
Voltage supply range +Vs:6 … 30 VDC
Current consumption max. (no load):12 mA
Output circuit:PNP make function (NO)
Voltage drop Vd:<2 VDC
Output current:200 mA
Mechanical data
Design:Cylindrical threaded
Material (sensing face):LCP
Housing material:Stainless steel
Dimension:5 mm
Housing length:45 mm
Connection types:Connector M8
Tightening torque max.
2 Nm (Front: 1,4 Nm)
Ambient conditions
Operating temperature:-25 … +75 °C
Protection class:IP 67
