Baumer IGYX 08P17B3/S35L Inductive proximity switch
General data
Mounting type: Flush
Nominal sensing distance Sn2 mm
Assured sensing distance Sa1.6 mm
Temperature drift: ± 10 % Sr (0 ... +60 °C)
Hysteresis: 3 ... 20 % Sr
Output indicator: 3-port red LED
Electrical data
Switching frequency: 3 kHz
Supply voltage range: +Vs: 10 ... 30 VDC
Maximum current consumption: (no load) 15 mA
Output circuit
PNP normally open function (NO)
Voltage drop Vd: <2.5 VDC
Output current 200 mA
Short-circuit protection: yes
Reverse polarity protection: yes
Mechanical parameters
Design: Cylindrical thread
Material (sensing face): PBT, red
Housing material: Stainless steel
Dimensions: 8 mm
Housing length: 36 mm
Connection type: M8 connector
Maximum tightening torque: 5 Nm
Environmental conditions
Operating temperature: -25 … +75 °C
Protection class: IP 67
