Power Supply
Rated Power Supply Voltage Us: AC/DC 24-270 V
Voltage Tolerance: +10% / -15%
Power Consumption: < 12 VA
Frequency: 50/60 Hz
Relay Output
Number and Type of Contacts: 11 changeover contacts
Contact Type: Type 3
Maximum Load Capacity: 5 A / 1250 VA
Input
Rated Insulation Voltage Ui: 250 V (EN 61010)
Rated Impulse Voltage: 4000 V
Current Sensor Input (S1) Power Supply: DC 17-21 V
Current Sensor Input (S1) Maximum Current: Maximum 120 mA (when Us=230 V) / Maximum 10 mA (when Us=24 V)
Command Input (e.g., external dust-clearing command) Internal Power Supply: +DC 24 V
Command Input Internal Resistance: Approximately 15 kΩ
Environment
Rated Ambient Temperature Range: -20°C ... +45°C
Structure and Installation
Enclosure/Mounting Bracket: V8 / Front Mounting Kit ER8 (8 TE)
Dimensions (Height x Width x Depth): 90 x 140 x 58 mm (mounting height 55 mm)
Mounting Method: 35 mm DIN rail or M4 screws
Wiring: 1 x 1.5 mm² per pole
Enclosure Protection Rating: IP 30
Terminal Protection Rating: IP 20
Vibration Resistance: 1 mm (25 Hz), 10 g (25-100 Hz, 20 ms)
Shock Resistance: 20 g (4 ms)
Weight: Approximately 350 g
