Power Supply Voltage Us: AC/DC 24–240 V (DC 20.4–297 V, AC 20–264 V)
Frequency: 0/50/60 Hz
Power Consumption: < 2 W, < 3 VA
Measurement Signals:
0/4–20 mA (input resistance 20 Ω)
0–10 V (input resistance 63 kΩ)
Switchable to 4–20 mA / 2–10 V
Switching Points (Limits):
Adjustable range: 0–100%
Hysteresis:
Adjustable range: 5–30% of the set limit
Setting Error:
< 10% of full scale
Repeatability Error:
< 0.2%
Temperature Dependency:
≤ 0.05 %/K
Startup Delay:
Adjustable range: 0.1–10 s
Switching Delay:
Adjustable range: 0.1–10 s
Relay Output:
1 changeover contact (CO)
Operating Mode:
Operating current mode or closing current mode can be selected via bridging
Display:
LED indicates operating status
Ambient Temperature Range:
-20°C to +55°C
Dimensions (Height × Width × Depth):
90 × 35 × 58 mm (mounting height 55 mm)
Installation Method:
35 mm DIN rail (EN 60715) or M4 screws
Protection Rating:
IP 30 / IP 20
Weight:
Approximately 130 g
