Sensor Type: Pt100 (3-wire system)
Operating Mode: Normally Closed Mode / Operating Current Mode (selectable via bridging)
Range Selection: -10...+40 °C / 0...100 °C / 0...200 °C
Setting Error: ±5 K
Repeatability Error: Approximately 0.5 K
Temperature Dependency: ≤ 0.05 %/K
Hysteresis: Adjustable 2...10 K
Switching Delay (don/doff): Adjustable 0.1...10 s
Relay Output: 1 changeover contact (co)
Contact Type: Type 3 (refer to general technical information)
Supply Voltage Us: AC/DC 24–240 V (DC 20.4–297 V, AC 20–264 V), 0/50/60 Hz, < 2 W, < 3 VA
Ambient Temperature: -20 °C to +55 °C
Enclosure Dimensions (H×W×D): 90 × 70 × 58 mm (mounting height 55 mm)
Mounting Method: 35 mm DIN rail (EN 60715) or M4 screws
Protection Class: IP 30 / IP 20
Weight: Approximately 100 g
