Power Supply Specifications
Parameter Specification
Rated Power Supply Voltage AC/DC 24–240 V
Frequency 0/50/60 Hz
Voltage Tolerance AC 20–264 V, DC 20.4–297 V
Power Consumption < 5 VA, < 3 W
Input Specifications
Voltage Input
Input Range: DC 0/2–10 V
Input Resistance: 12 kΩ
Maximum Input Signal: DC 27 V
Full-Scale Error: 0.1%
Resolution: 14 Bit
Current Input
Input Range: DC 0/4–20 mA
Input Resistance: 18 Ω
Maximum Input Signal: DC 100 mA
Full-Scale Error: 0.5%
Resolution: 14 Bit
Pt100 Temperature Input
Type: 3-wire
Measurement Range: -200 to +800 °C
Error: ±0.5% or ±0.5 K
Resolution: 0.1 °C
Sensor Current: ≤ 0.6 mA
Temperature Coefficient: < 0.04 °C/K
Automatic Line Resistance Compensation
Output Specifications
Type: 2-channel output (common ground)
Voltage Output: DC 0/2–10 V
Error: 0.3% of full scale
Temperature Coefficient: < 0.01 %/K
Resolution: 11.6 Bit, < 3.1 mV
Load: ≥ 1 kΩ
Current Output: DC 0/4–20 mA
Error: 0.3% of full scale
Temperature Coefficient: < 0.015 %/K
Resolution: 11.6 Bit, < 6.1 μA
Load: ≤ 500 Ω
