IFM O1D100 Laser distance sensor
Reliable optical distance measurement up to 10 m
2 switching outputs; one of them can be programmed as an analog output
Adjustable measuring range and window function
Suitable for applications requiring background suppression
Excellent price/performance ratio
Operating voltage [V]: 18...30 DC; (in compliance with cULus - Class 2 standard)
Current consumption [mA]: < 150
Protection class: III
Maximum spot width [mm]: 15
Maximum spot height [mm]: 15
Reference spot size: 10 m
Background blanking [m]: 0...19
Ambient temperature [°C]: -10...60
Enclosure protection grade: IP 67
