Switching Point 2 A (+20% / -40%)
Turn-off Point Approximately 1.5 A
Use with Multiple Turns The switching point decreases with each additional turn (e.g., 4 turns → 0.5 A)
Output Type Open Collector
Maximum Output Voltage/Current DC 40 V / 40 mA
On-state Voltage Drop Maximum 3 V
Off-state Leakage Current Maximum 0.6 mA
Switching Delay Approximately 50 ms (on) / 200 ms (off)
Repeatability Accuracy ±5 %
Hysteresis Approximately 6 %
Temperature Dependency 0–55°C: <0.5 %/K; -20–0°C: <2.5 %/K
Overload Capacity Continuous 100 A; Maximum 300 A (10 seconds)
Rated Frequency 50 Hz
Frequency Range 30–70 Hz
Frequency Error ≤ 1 %/Hz
Operating Temperature -20°C to +55°C
Enclosure Type Type S
Dimensions (Diameter × Height) 34.5 mm × 27 mm
Wire Aperture 11 mm
Weight Approximately 60 g
Cable Length 1 m (2-wire system)
Protection Function Built-in reverse polarity protection diode
