Model: VB 230-25LT
Rated Equipment Current: 25 A
Power Supply Voltage: 220/240 V ±10%, 50/60 Hz
Power Consumption of Electronic Components: 3 VA
Recommended Rated Current Range of Motor: 2...12.5 A
Rated Equipment Current (Braking Time ≤ 20s): 25 A
Rated Equipment Current (Braking Time ≤ 30s): 17 A
Maximum Braking Frequency (Braking Time 5s): 1/60 s⁻¹
I²t Value (Power Semiconductor): 1250 A²·s
Braking Voltage: 0...110 V DC
Maximum Braking Time: 0...30 s (optional special equipment up to 60 s)
Control Relay Contact Rating: 3 A / 250 V AC; 3 A / 30 V DC
Residual Electromotive Force Reduction Delay: Self-optimizing, range 0.2...1.8 s
Maximum Connecting Wire Size: 2 × 2.5 mm² per terminal
Ambient Temperature (Operating): 0 °C...45 °C
Storage Temperature: -25 °C...75 °C
Weight: 0.6 kg
