Model: VB 230-30LT
Rated Equipment Current: 30 A
Power Supply Voltage (in compliance with DIN EN 50160 / IEC 38): 220/240 V ±10%, 50/60 Hz
Power Consumption of Electronic Components: 3 VA
Recommended Rated Current of Applicable Motor (Maximum): 2...15 A
Rated Equipment Current with Braking Time ≤ 20s: 30 A
Rated Equipment Current with Braking Time ≤ 30s: 20 A
Maximum Braking Frequency (with a Braking Time of 5s): 1/90 s⁻¹ (once every 90 seconds)
I²t Value of Power Semiconductor: 1350 A²·s
Braking Voltage: 0...110 V DC
Maximum Braking Time: 0...30 s (optional special equipment: 0...60 s)
Control Relay Contact Rating: 3 A / 250 V AC; 3 A / 30 V DC
Residual Electromotive Force Decay Delay: Self-optimizing range 0.2...1.8 s
Maximum Conductor Cross-Sectional Area for Terminals: 2 × 2.5 mm² per terminal
Ambient Temperature (Operating): 0 °C...45 °C
Storage Temperature: -25 °C...75 °C
Weight: 0.6 kg
