Model: VB 400-6LT
Power Supply Voltage (in compliance with DIN EN 50160): 380/415 V ±10%, 50/60 Hz
Power Consumption of Electronic Components: 3 VA
Recommended Rated Current Range of Motor: 0.3 … 3 A
Rated Equipment Current (Braking Time ≤ 20 s): 6 A
Rated Equipment Current (Braking Time ≤ 30 s): 6 A
Maximum Braking Frequency (Braking Time 5 s): 1/8 s
I²t Value of Power Semiconductor: 310 A²s
Braking Voltage: 0 … 220 V DC
Maximum Braking Time: 0 … 30 s (optional special model: 0 … 60 s)
Control Relay Contact Rating: 3 A / 250 V AC; 3 A / 30 V DC
Residual Electromotive Force Decay Delay Time: Self-optimizing, range 0.2 … 1.8 s
Maximum Wiring Cross-Sectional Area: 2 × 2.5 mm² per terminal
Ambient Temperature: 0 °C … 45 °C
Storage Temperature: -25 °C … 75 °C
Weight: 0.6 kg
