Rated equipment current: 25 A
Power supply voltage (50/60 Hz): 220/240 V ±10%
Optional wide voltage range (Option B): 200…575 V ±10%
Power consumption of electronic unit: 6 VA
Recommended for rated motor current (maximum): 12.5 A
Maximum braking current duty factor (c.d.f.): 8%
Power semiconductor I²t value: 1250 A²s
Braking voltage (DC): 0…130 VDC (corresponding to 220/240 V input)
Maximum braking time: 15 seconds (other durations can be customized)
Control relay contact rating: 6 A / 250 VAC; 6 A / 30 VDC
Residual electromotive force decay delay time: Self-optimizing range 100…2500 ms
Maximum wiring cross-sectional area: 2 × 2.5 mm² per terminal
Ambient temperature: 0°C…+45°C
Storage temperature: -25°C…+75°C
Weight: 0.8 kg
