Model: VB 400-25LT
Main Voltage (in accordance with DIN EN 50160): 380/415 V ±10%, 50/60 Hz
Power Consumption of Electronic Equipment: 3 VA
Recommended Rated Motor Current Range: 2 … 12.5 A
Rated Equipment Current (Braking Time ≤ 20 s): 25 A
Rated Equipment Current (Braking Time ≤ 30 s): 17 A
Maximum Braking Frequency (Braking Time 5 s): 1/60 s (once per minute)
I²t Value (Power Semiconductor): 1250 A²s
Braking Voltage: 0 … 220 V DC
Maximum Braking Time: 0 … 30 s (special version available for 0 … 60 s)
Control Relay Contact Rating: 3 A / 250 V AC; 3 A / 30 V DC
Residual Electromotive Force Reduction Delay Time: Self-optimizing range 0.2 … 1.8 s
Maximum Connection Cross-Sectional Area (per terminal): 2 × 2.5 mm²
Ambient Temperature: 0 … 45 °C
Storage Temperature: -25 … 75 °C
Weight: 0.6 kg
