Model: VB 400-30LT
Rated Equipment Current (Braking Time ≤ 20s): 30 A
Rated Equipment Current (Braking Time ≤ 30s): 20 A
Main Power Supply Voltage (in compliance with DIN EN 50160 / IEC 38): 380/415 V ±10%, 50/60 Hz
Power Consumption of Electronic Circuit: 3 VA
Recommended Rated Current Range for Adapted Motor: 3 … 15 A
Maximum Braking Frequency (Braking Time 5s): 1 time per 90 seconds
I²t Value of Power Semiconductor: 1350 A²s
Braking Voltage: 0 … 220 V DC
Maximum Braking Time: 0 … 30 s (customizable version available for 0 … 60 s)
Control Relay Contact Rating: 3 A / 250 V AC; 3 A / 30 V DC
Residual Back Electromotive Force Decay Delay: Self-optimizing, range 0.2 … 1.8 s
Maximum Conductor Cross-Sectional Area of Connection Terminals: 2 × 2.5 mm² per terminal
Operating Ambient Temperature: 0 °C … 45 °C
Storage Temperature: -25 °C … 75 °C
Weight: 0.6 kg
