PHOENIX GDT-US-NG/40-P Surge Protection Plug
Brand: PHOENIX CONTACT
Model: GDT-US-NG/40-P
Model Number Breakdown
GDT-US: Gas discharge tube surge protection module series
NG: Product version code
40: Max. discharge current Imax = 40kA (8/20μs)
P: Plug-in module, base ordered separately
| Item | Specification |
|---|---|
| Protection Class | Type 2 |
| Max. Continuous Voltage Uc | 305V AC |
| Nominal Discharge Current In | 20kA |
| Max. Discharge Current Imax | 40kA |
| Protection Element | Gas discharge tube (GDT) |
| Voltage Protection Level Up | ≤1.8kV |
| Operating Temperature | -40°C to +80°C |
| Protection Rating | IP20 |
| Module Width | 17.5mm |
| Weight | Approx. 0.042kg |
| Approvals | IEC61643-11, EN61643-11, UL |
Features
GDT protection core, extremely low capacitance, suitable for capacitance-sensitive circuits. Plug-in modular structure, hot swappable. Visual status window for quick failure identification. Compact 17.5mm width. Optional remote signaling contact on base. Low leakage current and slow aging.
Applications
Low-voltage distribution cabinets, PLC control cabinets, machine tool electrical controls, photovoltaic auxiliary circuits, industrial instrument power supply circuits.
