Phoenix QUINT-DIODE/12-24DC/2X20/1X40 Redundancy module
DIN rail diode module 12-24 V DC/2x20 A or 1x40 A. Uniform redundancy up to the consumer.
A safe redundant system is the result of the parallel connection of two power supply units which are decoupled from one another. To further increase system availability, QUINT DIODE provides the solution: decoupling with diode.
| Nominal input voltage range | 12 V DC ... 24 V DC |
| Input voltage range | 10 V DC ... 30 V DC |
| Voltage type of supply voltage | DC |
| Reverse polarity protection | < yes60 V |
| Nominal input current (IN) | 2x 20 A (-25 °C ... 60 °C) |
| 1x 40 A (-25 °C ... 60 °C) | |
| Maximum current Imax | 2x 30 A (-25 °C ... 40 °C) |
| 1x 60 A (-25 °C ... 40 °C) | |
| Transient surge protection | Varistor |
| Voltage drop, input/output | typ. 0.5 V |
| Nominal input voltage range | 12 V DC ... 24 V DC |
| Input voltage range | 10 V DC ... 30 V DC |
| Input voltage range DC | 10 V DC ... 30 V DC |
